首页>> 传感器类>> 压力变送器>> L117 L127Pressure Transmitter压力变送器WISE SENSOR INC

L117
商品名称:L117 L127Pressure Transmitter压力变送器WISE SENSOR INC
商品品牌 :WISE SENSOR 订购电话 :0760-88886370 88886371 88886372 88886373 88732779
传真热线:0760-88306579 : 1分
浏览次数: 3412 剩余数量: 100 件
本站价 :¥1.00 优惠价 :¥1.00
数量 你的价格: 1.00
会员评级 评论星级 我要评级
详细信息 优惠信息 配送信息 售后服务




Submersible Depth And Level Pressure Transmitter
潜水深度和水平压力变送器
Advantages GGGGGGGGGGGGGGGGGGGGGGGGGGGGGGGGeeeeeeeeeeeeeeeeeeeeeeeennnneenneenneeeennnnnnnnnnnnnnnnnnnnnnnneneeeeeeeeeeeeeeeeeeeeeeeerrrrerreerreeerrrrrrrrrrrrrrrraaaarraarraarrraaaaaaaaaaaaaaaaaalllaallaallallllllll llll ll DDllDDll DDlllDD DD DDDD DDDDDDDDDDDDDDeeeeeeeeeeeeeeeeeeeeeeeessssseesseesseeeesssssssssssscssccccccssccssccssssssccsccccccccccccrrrrccrrccrrccccrrrrrrrrrrrrrrriiiiirriirriirrriiiiiippiiiippppiippiippiippiippiiiippppiiipppppppppppppptpttttttttttttttttttiiittiiiittiittiittiittttitttooiiiiooooiiooiiooiiooiiooiiiiooooiiioooooooonnoonnoonnonnnnnnnnnnnnnnnnnnnnnnnnn
􄤎High precision and fully submersible
depth & level pressure transmitters
􄤎All stainless steel 316 construction
􄤎Measuring ranges from 0.1 to
35kgf/cm2
􄤎Tow-wire loop powered 4~20mA DC
output signal
􄤎Excellent accuracy and long term
stability
􄤎300% proof pressure
􄤎Excellent urethane extension cable with
vented tube
Applications
Any environment where reliable 4~20mA
continuous level measurement in ;
􄤎Ground and surface water monitoring
􄤎Water supply and reservoirs controls
􄤎Deep well measurements
􄤎Geophdrological investigations of
ground water elevation
􄤎Well and borehole probe
􄤎Water filtration plants and waste water
treatment
L100 series submersible depth and level pressure
transmitters with a reliable vented cable meet IP68
requirements for permanent submersion. They are
specially designed for applications where access for
installation is restricted and continuous level
measurement of liquids in various ranges to a maximum
equivalent of 350 meters of hydrostatic water pressure
such as deep wells or buried storage vessels.
The transmitter has a perfect water resistant, stainless
steel housing for complete protection from harsh
environments and its 4~20mA current output is ideal for
remote monitoring of both primary and secondary
process variables.
The transmitters are available as absolute or relative
pressure with either 2-wire current or 3-wire voltage
output.
The pressure to be measured acts through thin corrosion
resistant stainless steel 316L diaphragm on a silicon
measuring element. The pressure transmitting medium is
silicon oil. The measuring element contains diffused
piezoresistive resistors which are connected into a
Wheatstone bridge. The output signal of this bridge is
temperature compensated and converted into a
standardized current or voltage output signal.
Model L127 L117
Technology Piezoresistive silicon pressure sensor Piezoresistive ceramic pressure sensor
Pressure ranges 0~0.1 to 35kgf/cm2 relative pressure 0~0.5 to 35kgf/cm2 relative pressure
0~1 to 35kgf/cm2 absolute pressure 0~1 to 35kgf/cm2 absolute pressure
Pressure reference Gauge, absolute
Overload 3×full scale without damage 1.5×full scale without damage
Output signal 4~20mA current output
Electrical connection type 2-wire technique
Full scale output signal 20mA : ±0.2% 20mA : ±0.3%
Zero measured output 4mA : ±0.03% 4mA : ±0.15%
Other signals available on request
Excitation voltage 12~36V DC
Load resistance max@24V 500Ω at 24V
Influence of excitation 0.01% FSO/V
Power ripple ≤500mV P-P
Reverse polarity Protected
Shock resistance No change in performance after 10Gs for 11ms
Vibration 0.1G (1 m/s/s) maximum
Response time(10~90%) ≤2 milliseconds 1.5miliseconds
Adjustment ±10% FSO/zero and span ±10% FSO/zero and span
Accuracy ≤±0.25% FSO ≤±0.5% FSO(optional)
Non-linearity ±0.100% FSO typical ±0.20% FSO
Repeatability ±0.015% FSO typical ±0.10% FSO typical
Pressure hysteresis ±0.010% FSO typical ±0.10% FSO typical
Long term stability ±0.3% FSO over 6 month
Cutoff frequency(-3 d B) ±2kHz
Reference temperature 35°C 25°C
Operating temperature range -40~125°C -40~125°C
Compensated temperature range 0~82°C 0~70°C
Thermal sensitivity shift ≤±0.2%FSO ≤±0.015%/°C typical
Thermal zero shift ≤±0.2%FSO ≤±0.02%FSO/°C typical
Thermal hysteresis ≤±0.1% FSO ≤±0.2%FSO
Process connection PT3/8″with removable stainless steel nose cone
Weight or flange can be available
Other connections available on request
Process media Water and liquids compatible with
Stainless steel 316 Ceramic Al2 O3, 96%
Materials wetted by process Diaphragm : Stainless steel 316L Ceramic Al2 O3, 96%
Housing : Aluminum die-casting terminal head
Gasket O-ring : Viton (HNBR, CSM, Teflon etc.)
Construction of extension cable 4 core, shielded with vented tube
ф7.7mm diameter
Vented Polyurethane cable
Stainless steel extension pipe version available(optional)
Enclosure rating IP68
Weight Approx. 400g without cable
Options General terminal head
Explosion proofed terminal head (Ex d IIC T6)
Local display unit
Note :① It should be installed with a support wire over 200meter depth measurement.
